💡 Product Overview
The Type-C Emergency Light Charging Module is a compact and multifunctional control board designed for building or repairing rechargeable emergency lights, LED torch lights, and portable lighting projects. This module combines battery charging, LED brightness control, battery protection, and power management into a single PCB, making it an ideal solution for DIY electronics enthusiasts, repair technicians, and manufacturers.
Designed for use with one 3.7V 18650 lithium-ion battery, the board features a modern Type-C USB charging port for fast and convenient charging. It also includes three-level LED brightness control, allowing users to switch between different light intensity levels according to their needs.
Available from Rafiq Electronics, this module is an excellent choice for repairing old emergency lights or creating custom rechargeable lighting projects.
⚡ Technical Specifications
✅ Product Type: Emergency Light Charging Controller Module
✅ Battery Type: 1 × 3.7V 18650 Lithium-Ion Battery
✅ Charging Port: USB Type-C
✅ Charging Voltage: 5V DC
✅ LED Brightness Levels: 3 Levels
✅ Brightness Control: Push Button Switching
✅ Battery Protection: Built-in Charging & Discharging Protection
✅ Application: Rechargeable Emergency Light & Torch
✅ PCB Type: Compact DIY Controller Board
🔋 Battery Charging Features
The integrated charging circuit makes charging simple and safe.
✅ Supports 5V USB Type-C charging
✅ Designed for 3.7V 18650 Lithium-Ion battery
✅ Automatic charging management
✅ Convenient USB charging from adapters, power banks, laptops, and USB chargers
The Type-C connector provides a modern and reliable charging solution.
💡 3-Level LED Brightness Control
This module allows easy adjustment of LED brightness according to your requirements.
🔆 High Brightness Mode
🔅 Medium Brightness Mode
✨ Low Brightness Mode
The multi-level dimming feature helps save battery power while providing the required illumination.
🛡️ Protection Features
✅ Battery overcharge protection
✅ Battery over-discharge protection
✅ Stable charging management
✅ Safe battery operation
These protection functions help improve battery life and provide safer operation during daily use.
🛠️ Applications
🔦 Rechargeable Torch Lights
💡 LED Emergency Lights
🏕️ Camping Lights
🛠️ Emergency Light Repair
🔋 DIY Rechargeable Lighting Projects
🏠 Portable LED Lamps
⚙️ Electronics Learning Projects
This controller board is suitable for new projects as well as repairing damaged emergency light circuits.
⭐ Key Features & Highlights
✅ USB Type-C charging port
✅ Supports one 3.7V 18650 lithium battery
✅ 3-level LED brightness control
✅ Built-in battery charging circuit
✅ Charging and discharging protection
✅ Compact PCB design
✅ Easy installation
✅ Ideal for DIY and repair work
✅ Quality supplied by Rafiq Electronics
🧰 Installation
🔧 Connect the 3.7V lithium battery correctly.
🔧 Connect the LED output according to polarity.
🔧 Use a standard 5V USB Type-C charger.
🔧 Use the push button to switch brightness levels.
Always verify wiring before powering the module.
⚠️ Important Notes
⚠️ Designed only for one 3.7V 18650 lithium-ion battery.
⚠️ Observe correct battery polarity.
⚠️ Do not short-circuit battery terminals.
⚠️ Use a quality 5V USB power adapter.
⚠️ LED load should be within the module’s supported capacity.
🔍 Why Choose This Module?
Instead of using separate charging boards, dimmers, and protection circuits, this module combines all essential functions into one compact PCB. Its Type-C charging port, 3-level brightness control, and battery protection make it an ideal solution for repairing or building rechargeable emergency lights and torch lights. Whether you’re a technician, student, or DIY enthusiast, this module offers convenience, reliability, and ease of installation.
