The BD140 Transistor is a medium-power PNP silicon transistor built for switching and linear amplifier applications. Its specifications and packaging make it ideal for use in audio stages, driver circuits, and general-purpose electronics. The BD140 complements its NPN counterpart (such as the BD139) in push-pull or complementary amplifier designs.
At Rafiq Electronics, we supply authentic BD140 transistors tested for reliability and consistent performance, so whether you’re making a DIY amplifier or repairing electronic equipment, you can trust this component.
✅ Key Features
-
✅ PNP Configuration: Ideal for PNP side of complementary transistor pairs.
-
✅ Collector Current up to 1.5 A (-1.5 A for PNP): Suitable for moderate output applications.
-
✅ Collector-Emitter Voltage (Vce) up to 80 V: Enough headroom for many audio/switching uses.
-
✅ TO-126 Package: Easy to mount on a heatsink for improved dissipation.
-
✅ Complement to BD139/BD135 family: Enables paired configurations in amplifier circuits.
-
✅ Stable gain (hFE) at various currents: Ensures predictable performance.
⚙️ Technical Specifications
| Parameter | Value | Notes |
|---|---|---|
| Type | PNP Silicon Transistor | General-purpose medium power |
| Maximum Collector-Emitter Voltage (Vce) | 80 V | |
| Maximum Collector Current (Ic) | 1.5 A (-1.5 A for PNP) | |
| Power Dissipation (Pc) | 12.5 W (at Tc = 25°C) | |
| Transition Frequency (fT) | ~50-190 MHz typical range | |
| Package | TO-126 (also SOT-32) |
🧰 Applications
-
🔊 Audio amplifier driver stages – PNP transistor in push-pull arrangements.
-
⚙️ Switching and drive circuits – moderate current switching tasks up to ~1.5 A.
-
💡 General-purpose electronics repair – replacing older PNP transistors in boards.
-
🏠 DIY electronics & hobby projects – reliable component for learners and tinkerers.
